ESR07- SIMULATING ANISOTROPIC MATERIAL


ESR07- SIMULATING ANISOTROPIC MATERIAL
ESR: Efilena Baseta
ESR NUMBER: ESR7
INDUSTRIAL PARTNERS: Cloud9 + Blumer Lehmann
INSTITUTE: Ioa
IMG_6695!!_



Description:

Load bearing structures generally show preferred directions for channelling internal forces that depend on geometry and prevailing support conditions (anisotropy). Current material practice does not take advantage of anisotropic material properties. However, anisotropy can be designed by placing oriented fibres in a matrix that glues them together (e.g. wood, bone), introducing small scale geometric modulations (e.g. corrugation) or differentiating material density (e.g. porosity gradient) and are interesting models for material optimisation. This project delivers new methods for simulating anisotropic materials. Finite Element Method (FEM) forms a proven and reliable method for anisotropic simulation. However these are computationally heavy and lack the flexibility to deal with complex geometries efficiently. With a focus on timber lamination, this project will develop new intuitive and light-weight parametric design methods that combine with structural assessment tools allowing design solutions to be optimised in respect to the interrelation between structural geometry, fabrication constraints, production cost and structural performance.

Efilena Baseta

Efilena_mbnIMG_5767-Square-1000x1000

IOA / ESR07- SIMULATING ANISOTROPIC MATERIAL

Efilena Baseta is an architect engineer, studied in the National Technical University of Athens (NTUA), with a Master degree in Advanced Architecture from the Institute for Advanced Architecture of Catalonia (IAAC). Her interest lies in exploring material behaviors, physically and digitally, in order to create real time responsive structures. Since 2014 Efilena is a partner of Noumena, an… read more



Posts

Digital Design & Full Scale Fabrication Course – IoA

Author: Efilena Baseta

DYNAMIC ACTIVE BENDING STRUCTURES “The form is a system which organises itself in the presences of both internal and external forces and these organizations can shape patterns traced through mathematical rules.”D’ Arcy Thompson In this framework, this 5-days course focuses on the creation of controllable, dynamic, active-bending timber sctructures, using loads as the actuators. The... read more

Keywords:

Open Lecture TU Graz : Adaptive structures and material performance

Author: Efilena Baseta

This week Efilena Baseta visited TU Graz as a jury member of the midterm presentation of the studio ”Break it till you Make it” led by Urs Hirschberg. The students focus on experimenting on various materialities of wood with the final goal of building an 1:1  info point. After the reviews followed the open lecture on ”Adaptive Structures and... read more

Keywords:

Blumer Lehmann secondment

Author: Efilena Baseta

          The last months I have been working on scaling up the micro-scalar (1 dm) dynamic behaviour of wood veneer into macroscalar dynamic wooden structures (10m) exploring active bending techniques. From the 6th till the 18th of November  I conducted my secondment in Blumer Lehman in Gossau, Switzerland with the aim to construct... read more

Keywords:
